Front View Camera Replacement (Object Lens Cleaning)

Fig 1: Identifying Front View Camera (Object Lens)

Courtesy of SAAB-SCANIA OF AMERICA, INC.

Callout	Component Name
Preliminary Procedure  For cleaning the front view camera lens remove the front view camera. Refer to FRONT VIEW CAMERA REPLACEMENT (OBJECT LENS CLEANING)  or FRONT VIEW CAMERA REPLACEMENT (BASE) .
1	Front View Camera Procedure  Blow off the dust from the lens and clean the lens only with a dampish cloth in order to avoid direct wetness and a damage of the lens. Clean the windscreen with glass cleaner and dry the screen until there are no cords. Install the camera and go for a functional test drive. Refer to VEHICLE DIRECTION ALERT ALARM WARNING MODULE PROGRAMMING AND SETUP . NOTE: Cleaning Supplies For the lens: glasses cleaner or microfiber cloth or kitchen roll. For the windscreen: water with dish liquid, glass cleaner for car screens.
