Transmission Identification: Notes

Transmission codes and production dates -arrow 1-. Refer to LASER ENGRAVED ON THE TRANSMISSION .

Transmission codes and production dates on the transmission fluid pan -arrow 2-. Refer to LABEL ON THE TRANSMISSION FLUID PAN .

Fig 1: Rear Body Dimensions And Measurement Points
GWWM00-10323Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
