Front Peripheral Camera -R243-, Removing And Installing: Removing

-- Turn off the ignition and all electrical equipment.

-- Move the ignition key outside of the vehicle to prevent switching on the ignition unintentionally.

-- Remove the license plate holder. Refer to BUMPER COVER, REMOVING AND INSTALLING .

-- Disconnect the connector -4- from the peripheral camera -3-.

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- Release the bracket -2- from the hooks -1- and from the peripheral camera -1-.

-- Remove the bolts -3-.

-- Remove the peripheral camera from the license plate holder.
