Test Step 4 - Liftgate Switch Sense Circuit Open

Fig 1: Testing For Liftgate Switch Sense Circuit Open

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

• Turn the ignition OFF.
• Measure the resistance of the liftgate switch sense circuit between the switch connector and the power liftgate C2 harness connector.

Is the resistance less than 2.0 ohms?

No

• Repair the liftgate switch sense circuit for an open.
• Perform the Body Verification Test. Refer to BODY VERIFICATION TEST .

Yes

• Replace the power liftgate module. Refer to POWER LIFTGATE CONTROL MODULE .
• Perform the Body Verification Test. Refer to BODY VERIFICATION TEST .
