Special tools and equipment

Torque wrench VAG 1331 (5 - 50 Nm)

Fig 1: Identifying Special tool - Torque Wrench VAG 1331 (5-50 Nm)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE: The Motronic control module requires the No. 1 cylinder TDC signal from the Camshaft Position (CMP) sensor to allocate the injection and knock sensor systems as per firing order.
