Front Speed Sensor: Components

Fig 1: Identifying Front Speed Sensor Components (1 Of 2)
G06120704Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Identifying Front Speed Sensor Components (2 Of 2)
G05417820Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
