Floor Shift Lever ASSY (MTM): Components

WARNING: This page is about a different variant/trim than selected.
Fig 1: Exploded View Of Floor Shift Lever Assembly Components
G00921605Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
