- Open the LH front door and lower the LH front window.
- Use the touchscreen to clear DAS Calibration. Wait for the prompt to automatically disappear before continuing.
NOTE:
Controls > Service > Camera Calibration > Clear Calibration
NOTE:
Verify the calibration was cleared successfully.
NOTE:
"Calibration in Progress" message and progress icon will appear during the next drive cycle.
- Remove the lower quad camera cover. See QUAD CAMERA COVER - LOWER (REMOVE AND REPLACE)
.
- Remove the rear view mirror. See MIRROR - REAR VIEW (REMOVE AND REPLACE)
.
- Remove the triple camera hood. See HOOD - TRIPLE CAMERA (REMOVE AND REPLACE)
.
- Disconnect the electrical harness from the occupant camera on the inside of the upper quad camera cover, and then remove the camera cover from the vehicle.
- Remove the screws (x4) that attach the triple camera assembly to the windshield bracket, and then release the assembly from the bracket.
 Courtesy of TESLA, INC.
|
- Disconnect the electrical connector from the humidity and temperature sensor.
 Courtesy of TESLA, INC.
|
- Use a PH00 (Phillips #00) screwdriver to remove the screws (x2) that attach the humidity and temperature sensor to the windshield bracket.
NOTE:
Use the correct screwdriver to remove the screws, otherwise it might strip the screw heads.
NOTE:
The screws are tiny, make sure not to misplace them.
 Courtesy of TESLA, INC.
|
- Remove the relative humidity and temperature sensor from the windshield bracket.
NOTE:
Angle the sensor circuit board up and over the plastic alignment pin, and then move the sensor circuit board upwards to clear the pin.
 Courtesy of TESLA, INC.
|
