Front Door Window Regulator Removal and Installation: Installation

Reference: FRONT DOOR WINDOW REGULATOR INSPECTION

Reverse removal procedure noting the following instruction.

• Apply grease to sliding portions of window regulator.

  : Grease 99000-25010

• Tighten front door window regulator attaching bolts to proper tightening order.

  Front door window regulator bolt tightening order

  (a) --> (b) --> (c)

  Fig 1: Applying Grease To Sliding Portions Of Window Regulator

  Courtesy of SUZUKI OF AMERICA CORP.
