DTC P0107: Manifold Absolute Pressure Sensor Low Input: Notes

Fig 1: DTC P0107: Manifold Absolute Pressure Sensor Low Input - System Wiring Diagram

G01985154

Courtesy of SUZUKI OF AMERICA CORP.
