Non-Turbo Model

WARNING: This page is about a different variant/trim than selected.
  1. Open the front hood, and remove the upper grille bracket from the front hood.
    Fig 1: Locating Upper Grille Bracket Bolt
    G09475882Courtesy of SUBARU OF AMERICA, INC.
  2. Using a marker pen, make alignment marks (A) on both the front hood striker and the front hood.
    Fig 2: Identifying Alignment Marks On Front Hood And Striker
    G09475883Courtesy of SUBARU OF AMERICA, INC.
  3. Remove the front hood striker from the front hood.
    Fig 3: Locating Front Hood Striker Bolts
    G09475884Courtesy of SUBARU OF AMERICA, INC.
  4. Remove the front center grille assembly from the front hood.
    Fig 4: Locating Front Center Grille Assembly Bolts
    G09475885Courtesy of SUBARU OF AMERICA, INC.
  5. Change the front hood damper mounting position from (A) to (B), and completely open the front hood.

    Tightening torque:

    20 N.m (2.0 kgf-m, 14.8 ft-lb)

    Fig 5: Identifying Front Hood Damper Mounting Position
    G09475886Courtesy of SUBARU OF AMERICA, INC.
  6. Remove the V-belt covers.
    Fig 6: Locating V-Belt Covers Bolts
    G09475887Courtesy of SUBARU OF AMERICA, INC.
  7. Disconnect the ground cable from battery.
  8. Remove the air intake duct (rear). Ref. to INTAKE (INDUCTION) (H4DO) > Air Intake Duct >  REMOVAL  .
  9. Remove the clip (A) from the air intake boot.
  10. Loosen the clamp (B) securing the air cleaner case (rear) to the air intake boot.
  11. Loosen the clamp (C) which secures the throttle body to the air intake boot.
    Fig 7: Identifying Air Intake Boot Clip And Clamp
    G09475465Courtesy of SUBARU OF AMERICA, INC.
  12. Remove the air intake boot from the throttle body, and move it to the left side wheel apron.
    Fig 8: Identifying Air Intake Boot And Throttle Body
    G09475466Courtesy of SUBARU OF AMERICA, INC.
  13. Lift up the vehicle.
  14. Remove the under cover. Ref. to EXTERIOR/INTERIOR TRIM > Front Under Cover >  REMOVAL  .
  15. Drain the engine oil. Ref. to LUBRICATION(H4DO) > Engine Oil >  REPLACEMENT   .
  16. Remove the under cover front - transmission.
  17. Remove the front exhaust pipe. Ref. to EXHAUST(H4DO) > Front Exhaust Pipe >  REMOVAL  .
  18. Disconnect the oil level switch connector from the engine harness, and remove the clip (A) securing the harness.
    Fig 9: Locating Oil Level Switch Connector
    G08315830Courtesy of SUBARU OF AMERICA, INC.
  19. Remove the nuts which secure the engine mounting to the front crossmember. (Hydraulic engine mounting model)
    Fig 10: Locating Engine Mounting Nuts (Hydraulic Engine Mounting Model)
    G09476408Courtesy of SUBARU OF AMERICA, INC.
  20. Remove the nuts which secure the engine mounting to the front crossmember. (Solid engine mounting model)
    Fig 11: Locating Engine Mounting Nuts (Solid Engine Mounting Model)
    G08316842Courtesy of SUBARU OF AMERICA, INC.
  21. Remove the electric power steering gearbox. Ref. to POWER ASSISTED SYSTEM (POWER STEERING) > Electric Power Steering Gearbox >  REMOVAL  .
  22. Remove the front drive shaft LH. Ref. to DRIVE SHAFT SYSTEM > Front Drive Shaft >  REMOVAL  .
  23. Lower the vehicle.
  24. Disconnect the bulkhead connector from the transmission harness connector (A) and the inhibitor harness connector (B), and remove the transmission radio ground terminal (C) from the vehicle. (CVT model)
    Fig 12: Identifying Transmission Harness Connector, Inhibitor Harness Connector, Transmission Radio Ground Terminal
    G09475904Courtesy of SUBARU OF AMERICA, INC.
  25. Remove the pitching stopper.
    Fig 13: Locating Pitching Stopper
    G09475905Courtesy of SUBARU OF AMERICA, INC.
  26. Remove the transmission cover. (CVT model)
    Fig 14: Locating Transmission Cover (CVT Model)
    G09475906Courtesy of SUBARU OF AMERICA, INC.
  27. Remove the transmission harness stay and move to the engine side. (CVT model)
    Fig 15: Locating Transmission Harness Stay (CVT Model)
    G09475907Courtesy of SUBARU OF AMERICA, INC.
  28. Remove the bolt which holds the transmission harness to the control valve body, and turn the transmission harness clockwise till the bolt hole can be seen as shown in the figure, and tighten the bolt to temporary lock the harness. (CVT model)
    NOTE: This procedure is required to prevent the transmission harness from touching the vehicle body during engine removal/installation.
    Fig 16: Locating Control Valve Body Bolts
    G08316848Courtesy of SUBARU OF AMERICA, INC.
  29. Lift up the engine with a lifting device and wire ropes.
    CAUTION: When lifting up the engine, pay attention to the clearance of each part and be careful not to lift the engine too much, in order to prevent damaging the vehicle.
    Fig 17: Supporting Engine Using Lifting Device And Wire Ropes
    G08316851Courtesy of SUBARU OF AMERICA, INC.
  30. Remove the engine mounting LH from the engine.
    Fig 18: Locating Engine Mounting LH Bolts
    G10403878Courtesy of SUBARU OF AMERICA, INC.
  31. Remove clip (A) from the oil pan upper, and remove the oil level switch.
    Fig 19: Locating Oil Level Switch Bolts
    G09476529Courtesy of SUBARU OF AMERICA, INC.
