Circuit figure

WARNING: This page is about a different car, the 2014 Subaru BRZ. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Data Link Connector - Circuit Diagram (1 Of 2)
G08552972Courtesy of SUBARU OF AMERICA, INC.
Fig 2: Data Link Connector - Circuit Diagram (2 Of 2)
G08552973Courtesy of SUBARU OF AMERICA, INC.
