Front Heat Shield Cover

WARNING: This page is about a different car, the 2004 Subaru Impreza. However, it is still accessible from the selected car via links, so may be relevant.

Loosen the four bolts to remove the front heat shield cover.

Fig 1: Removing Front Heat Shield Cover
G03511487Courtesy of SUBARU OF AMERICA, INC.
