Codes 14, 15, 16 & 17: Fuel Injectors

Fig 1: Schematic - Codes 14, 15, 16 & 17, Fuel Injectors
G91B18359
Fig 2: Flow Chart - Codes 14, 15, 16 & 17, Fuel Injectors
G91D17577
Fig 3: Code 13, Flow Chart Diagnostic Aids
G00106584Courtesy of SUBARU OF AMERICA, INC.
