Engine Compartment Relay Location Main Fuse: Notes

For additional information, refer to Figure.

Fig 1: Engine Compartment Relay Location Main Fuse Identification
G00583897Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Engine Compartment Relay Location Main Fuse Identification Legend

Fuse System
60A EPAS EPS
200A STR Charging
200A STR Starting
200A STR Wireless Door Lock Control
