Crankshaft Position Sensor Replacement

Fig 1: Identifying Crankshaft Position Sensor Components

Courtesy of SAAB-SCANIA OF AMERICA, INC.

Callout	Component Name
Preliminary Procedure  Remove the catalytic converter. Refer to TECHNICAL DATA .
1	Heater Outlet Pipe Fastener (Qty: 2) Refer to FASTENER CAUTION . Tighten  62 Nm (46 lb ft)
2	Heater Outlet Pipe NOTE: Do NOT remove the heater outlet pipe from the vehicle. Install NEW O-ring.
3	Exhaust Manifold Lower Heat Shield Lower Fastener Tighten  38 Nm (28 lb ft)
4	Exhaust Manifold Lower Heat Shield
5	Crankshaft Position Sensor Fastener Tighten  10 Nm (89 lb in)
6	Crankshaft Position Sensor Procedure  Disconnect the electrical connector.
