Driver or Passenger Seat Adjuster Memory Module Replacement (8-Way Power)

Fig 1: Identifying Driver Seat Adjuster Memory Module (8-Way Power)

Courtesy of SAAB-SCANIA OF AMERICA, INC.

Callout	Component Name
Preliminary Procedure  Disconnect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECTION AND CONNECTION . If a NEW ECM was installed, the ECM must be programmed. Refer to CONTROL MODULE REFERENCES .
1	Driver Seat Adjuster Memory Module Fastener (Qty: 4) Procedure  Move the driver or passenger seat full backward. Move the seat in upper position. Turn OFF the ignition. Disconnect the battery. Disconnect the wiring harness connector.
2	Front Seat Adjuster Memory Module
