Special Tools

Illustration	Tool Number/Description
Courtesy of GENERAL MOTORS CORP.	AU338 Fuel Pressure gauge
Courtesy of GENERAL MOTORS CORP.	AU453 Fuel Pressure Test Hose Adapter
Courtesy of GENERAL MOTORS CORP.	CH-48482 Fuel Sender Lock Ring Wrench
Courtesy of GENERAL MOTORS CORP.	EN-48536 Frame Support Tool (Engine Lower 65mm Kit)
Courtesy of GENERAL MOTORS CORP.	J 23738-A Vacuum Pump
Courtesy of GENERAL MOTORS CORP.	J 26792 Spark Tester
Courtesy of GENERAL MOTORS CORP.	J 33431-B Signal Generator and Instrument Panel Tester
Courtesy of GENERAL MOTORS CORP.	J 34730-E Fuel Pressure gauge Kit
Courtesy of GENERAL MOTORS CORP.	J 35616-200 Test Lamp Kit
Courtesy of GENERAL MOTORS CORP.	J 35616-A Connector Test Adapter Kit
Courtesy of GENERAL MOTORS CORP.	J 35689-A Metri-Pack Terminal Kit
Courtesy of GENERAL MOTORS CORP.	J 37027-1A IAC Motor Driver
Courtesy of GENERAL MOTORS CORP.	J 37088-A Fuel Line Quick Connect Separator
Courtesy of GENERAL MOTORS CORP.	J 37287 Inlet and Return Fuel Line Shut-off Adapters
Courtesy of GENERAL MOTORS CORP.	J 39021 Fuel Injector Coil/Balance Tester
Courtesy of GENERAL MOTORS CORP.	J 39194-B Oxygen Sensor Wrench
Courtesy of GENERAL MOTORS CORP.	J 39200 Digital Multimeter
Courtesy of GENERAL MOTORS CORP.	J 41413-SPT High Intensity White Light
Courtesy of GENERAL MOTORS CORP.	GE 41415-50 Fuel Tank Cap Adapter
Courtesy of GENERAL MOTORS CORP.	J 42598 Vehicle Data Recorder
Courtesy of GENERAL MOTORS CORP.	J 42960-2 Fuel Flapper Door Holder
Courtesy of GENERAL MOTORS CORP.	J 43244 Relay Puller Pliers
Courtesy of GENERAL MOTORS CORP.	J 44175 Fuel Composition Tester
Courtesy of GENERAL MOTORS CORP.	J 44602 Fuel Injector Test Adapter
Courtesy of GENERAL MOTORS CORP.	J 44603 Fuel Injector Test Lamp
Courtesy of GENERAL MOTORS CORP.	J 45004-1 Fuel Tank Drain Hose
Courtesy of GENERAL MOTORS CORP.	J 45722 Fuel Tank Lock Ring Remover
Courtesy of GENERAL MOTORS CORP.	CH 46843 Quick Connect Fitting Release Tool
Courtesy of GENERAL MOTORS CORP.	7370 Fuel Line Quick Connect Separator
Courtesy of GENERAL MOTORS CORP.	7371 Fuel Line Quick Connect Separator
Courtesy of GENERAL MOTORS CORP.	7000086I Scan Tool Used for diagnosis of vehicle electrical system.
