Removal Procedure

  1. Open the front door.
  2. Using J 36604  , remove the door hinge spring from the door hinge.
  3. Remove the door hinge spring from the vehicle.
    Fig 1: Removing Door Hinge Spring From Door Hinge Using J36604
    G01504111Courtesy of GENERAL MOTORS CORP.
