Removal Procedure

WARNING: This page is about a different car, the 2002 GMC Savana Special, 2002 GMC Savana Camper Special, 2002 GMC Savana, and 2002 Chevrolet Chevy Express. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the front door trim plate. Refer to Door Trim Plate Replacement (Manual Windows)  or Door Trim Plate Replacement (Power Windows)  or Door Trim Plate Replacement (Side/Rear Door)  .
  2. Remove the electrical connector (5) from the power door lock switch (7).
  3. Release the retaining tabs on the power door lock switch (7) from the front door trim plate (1).
  4. Remove the power door lock switch (7) from the front door trim plate (1).
Fig 1: Removing Power Door Lock
G01736950Courtesy of GENERAL MOTORS CORP.
