Installation Procedure

WARNING: This page is about a different car, the 2002 Pontiac Aztek and 2002 Buick Rendezvous. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the bulb to the instrument panel courtesy lamp socket.
  2. Install the instrument panel courtesy lamp socket turning clockwise.
  3. Install the left instrument panel insulator. Refer to CLOSEOUT/INSULATOR PANEL REPLACEMENT - LEFT .
    Fig 1: Installing Left Courtesy Lamp Bulb
    G01721231Courtesy of GENERAL MOTORS CORP.
