Test B: Left Front Door Unlock Inoperative With Transmitter

For test procedure, refer to illustration. See Fig 1 .

NOTE: POWER DOOR LOCKS SYSTEM CHECK is located in POWER DOOR LOCKS article.

Fig 1: Test B: Left Door Unlock Inoperative With Transmitter

Courtesy of GENERAL MOTORS CORP.
