Tailgate Power Window Inoperative From Panel Switch, Operates From Tailgate Switch
- With ignition on and tailgate open as a door, connect test lamp to ground and Pink wire terminal at panel switch. If lamp does not light, check for open in Pink wire or feed wire between fuse block and ignition. If lamp lights, move test lamp to Light Blue wire and press switch to "UP" position.
- If lamp does not light, replace instrument panel switch. If lamp lights, move test lamp to Tan/White terminal and press switch to "DOWN" position. If lamp does not light, replace instrument panel switch. If lamp lights, check motor ground and Light Blue and Tan/White wires.
