Exploded View
WARNING: This page is about a different variant/trim than selected.
Courtesy of NISSAN NORTH AMERICA, INC.
|
1.
|
EVAP canister bracket
|
2.
|
EVAP canister filter drain hose
|
3.
|
EVAP canister filter
|
|
4.
|
EVAP canister protector
|
5.
|
EVAP hose
|
6.
|
EVAP canister vent control valve
|
|
7.
|
O-ring
|
8.
|
EVAP canister
|
9.
|
EVAP canister control pressure sensor (with O-ring)
|
|
A.
|
Clip
|
B.
|
Nut
|
