User Mode

1. Turn the ignition switch from OFF to ON and check that the air bag warning lamp flashes.
2. Compare the flashing pattern with the examples in the table.
   Fig 1: Identifying Air Bag Warning Lamp

   Courtesy of NISSAN NORTH AMERICA, INC.

Air bag warning lamp flashing pattern (User Mode)

Warning lamp	SRS condition	Reference item
	No malfunction is detected. No further action is necessary.	-
	The system is malfunctioning and needs to be repaired.	Refer to "TROUBLE DIAGNOSIS WITH CONSULT " or "TROUBLE DIAGNOSIS WITHOUT CONSULT ".
	Zero point reset is incomplete	Refer to "ZERO POINT RESET: SPECIAL REPAIR REQUIREMENT ".
	Air bag is deployed. Seat belt pre-tensioner is deployed.	Refer to "FOR FRONTAL COLLISION " or "FOR SIDE AND ROLLOVER COLLISION ".
	Air bag diagnosis sensor unit is malfunctioning. Air bag power supply circuit is malfunctioning. SRS air bag warning lamp circuit is malfunctioning.	Refer to "AIR BAG WARNING LAMP DOES NOT TURN OFF ".
	Air bag diagnosis sensor unit is malfunctioning. Air bag warning lamp circuit is malfunctioning.	Refer to "AIR BAG WARNING LAMP DOES NOT TURN ON ".
