Removal and Installation: Removal

Disconnect the push-button ignition switch (1) fixing pawl using a remover tool (A), and then remove push-button ignition switch.

CAUTION: Always apply a protective tape (B) on instrument panel for protection.
Fig 1: Exploded View Of Push Button Ignition Switch
G08676799Courtesy of NISSAN NORTH AMERICA, INC.
