Retainer Plate (For Control Valve Upper Body)

WARNING: This page is about a different variant/trim than selected.

Refer to "CONTROL VALVE UPPER BODY ".

Fig 1: Retainer Plate Dimensions (For Control Valve Upper Body)
G00900407Courtesy of NISSAN MOTOR CO., U.S.A.
Fig 2: Identifying Retainer Plate Dimensions
G00900408Courtesy of NISSAN MOTOR CO., U.S.A.
