Section 7 (Manual Transaxle - RS5F70A)
>>
Service Data And Specifications (SDS)
>>
Available Thrust Washer
>>
MAINSHAFT Thrust Washer
MAINSHAFT Thrust Washer
WARNING:
This page is about a different variant/trim than selected.
Fig 1: Mainshaft Thrust Washer Specifications
Courtesy of NISSAN MOTOR CO., U.S.A.
