Wiring Diagram -Comm

WARNING: This page is about a different car, the 2004 Infiniti G35. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: For references to PG-POWER, see GROUND DISTRIBUTION & POWER DISTRIBUTION .

Fig 1: Wiring Diagram - AV-NAVI-05

Courtesy of NISSAN MOTOR CO., U.S.A.

Fig 2: Wiring Diagram - AV-NAVI-06

Courtesy of NISSAN MOTOR CO., U.S.A.
