Diagnostic Procedure

WARNING: This page is about a different car, the 2003 Nissan Murano. However, it is still accessible from the selected car via links, so may be relevant.

CHECK DTC
1. Turn ignition switch ON. (Do not start engine.)
2. Select SELF-DIAG RESULTS item at SELECT DIAG MODE.
3. Erase self-diagnostic results. Refer to HOW TO ERASE DTC .
4. Turn ignition switch OFF, and wait for 5 seconds or more.
5. Start engine.
6. Confirm self-diagnostic results again. Refer to SELF-DIAGNOSTIC RESULT TEST MODE .
IS THE LINE PRESSURE CONTROL DISPLAYED?
1. Yes: Replace the TCM. Refer to PRECAUTIONS FOR CVT ASSEMBLY REPLACEMENT "

  Fig 1: CONSULT-II SELF-DIAG RESULTS Display
  Courtesy of NISSAN MOTOR CO., U.S.A.
2. No: INSPECTION END
