Wiring Diagram - COMM -

WARNING: This page is about a different car, the 2007 Nissan Quest. However, it is still accessible from the selected car via links, so may be relevant.

For PG, go to POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Fig 1: AV-COMM-01 - Wiring Diagram
G04909272
Fig 2: AV-COMM-02 - Wiring Diagram
G04909273
Fig 3: AV-COMM-03 - Wiring Diagram
G04909274
