Variable Timing Control (VTC) Solenoid Maxima Se

Fig 1: Variable Timing Ctrl Solenoid Chart

Courtesy of NISSAN MOTOR CO., U.S.A.

NOTE: For California models, see appropriate Code 32 chart in TESTS W/CODES article. An EGR system malfunction should activate CHECK ENGINE light and set a code.

NOTE: For California models, see appropriate Code 51 chart in TESTS W/CODES article. A fuel injector malfunction should activate CHECK ENGINE light and set a code.
