DTC B1201: Abnormal Fuel Information: Notes

CAUTION: Whenever the ECU is replaced, ensure that the communication circuit is normal.
Fig 1: Fuel Gauge Unit Circuit Diagram
G00527939Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
Fig 2: Locating Fuel Gauge Unit Connectors
G00527940Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
