Removal And Installation (2.0L Engine Turbo): Notes

Fig 1: Removing/Installing Generator Assembly With Torque Specifications (2.0L Engine Turbo)

G07033883

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
