DTC U0401: Engine CAN data error: Notes

WARNING: This page is about a different variant/trim than selected.
Fig 1: Engine CAN Data Error - Circuit Diagram
G04871707Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
CAUTION:
  • If there is any problem in the CAN bus lines, an incorrect DTC may be set. Prior to this diagnosis, always diagnose the CAN bus lines.
  • Before replacing the ECU, ensure that the communication circuit is normal.
