>>C<< Transaxle Assembly Installation

WARNING: This page is about a different variant/trim than selected.
  1. Install the transaxle assembly. (M/T: Refer to , TRANSAXLE ASSEMBLY , A/T: Refer to , TRANSAXLE ASSEMBLY ).
  2. Remove from the car the two bolts, to assemble the radiator support upper insulator.
    Fig 1: Removing From Car Two Bolts, To Assemble Radiator Support Upper Insulator
    G04271084Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
