When Scan Tool MB991958 Is Used

WARNING: This page is about a different variant/trim than selected.

To carry out troubleshooting, operate scan tool MB991958 (MUT-III Sub Assembly) as follows.

Fig 1: Scan Tool Operating Flow Chart (1 Of 2)
G04279034Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
Fig 2: Scan Tool Operating Flow Chart (2 Of 2)
G04279035Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
