Radiator Fan Motor Check

WARNING: This page is about a different variant/trim than selected.
  1. Remove the radiator fan motor connector.
  2. Check to see that the fan motor of the radiator turns when applying battery power between the connector terminals of the radiator fan motor. Also check to see that there is no abnormal sound coming from the radiator fan motor at this time.
  3. If the radiator fan motor is defective, replace it.
    Fig 1: Connecting Terminal No.1 And Battery (-) Terminal. Terminal No.3 And Battery (+) Terminal
    G04271445Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
