Liftgate Handle, Lock and Latch - Exploded View

Fig 1: Liftgate Handle, Lock and Latch - Exploded View With Torque Specifications

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	14018	Liftgate latch release switch
2	74402A30	Liftgate molding
3	W709764	Liftgate molding nuts (4 required)
4	7483150	Liftgate latch
5	W505426	Liftgate latch bolts (3 required)

1. For additional information, refer to the procedures in this article.
