Removal/Installation Procedures

  1. Disconnect the negative battery terminal. (See NEGATIVE BATTERY TERMINAL DISCONNECTION/CONNECTION .)
  2. Remove the following parts:
    1. Driver-side front seat (See FRONT SEAT REMOVAL/INSTALLATION .)
    2. Front map light (See FRONT MAP LIGHT REMOVAL/INSTALLATION .)
    3. Sensor cover (See SENSOR COVER REMOVAL/INSTALLATION ).
    4. Sunvisor (See SUNVISOR REMOVAL/INSTALLATION .)
    5. Assist handle (See ASSIST HANDLE REMOVAL/INSTALLATION .)
    6. A-pillar trim (See A-PILLAR TRIM REMOVAL/INSTALLATION [L.H.D.] .)
    7. B-pillar upper trim (See B-PILLAR UPPER TRIM REMOVAL/INSTALLATION .)
    8. Second-row seat (See SECOND-ROW SEAT REMOVAL/INSTALLATION .)
    9. Second-row seat console box (with second-row seat console box) (See SECOND-ROW SEAT CONSOLE BOX REMOVAL/INSTALLATION .)
    10. Trunk covering (See TRUNK COVERING REMOVAL/INSTALLATION .)
    11. Trunk board (See TRUNK BOARD REMOVAL/INSTALLATION .)
    12. Trunk end trim (See TRUNK END TRIM REMOVAL/INSTALLATION .)
    13. Third-row seat cushion (See THIRD-ROW SEAT CUSHION REMOVAL/INSTALLATION .)
    14. Third-row seat back component (See THIRD-ROW SEAT BACK COMPONENT REMOVAL/INSTALLATION .)
    15. Trunk side upper trim (See TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION .)
    16. Rear scuff plate (See REAR SCUFF PLATE REMOVAL/INSTALLATION .)
    17. C-pillar trim (See C-PILLAR TRIM REMOVAL/INSTALLATION .)
    18. D-pillar trim (See D-PILLAR TRIM REMOVAL/INSTALLATION .)
    19. Trunk side trim (See TRUNK SIDE TRIM REMOVAL/INSTALLATION .)
    20. Headliner (See HEADLINER REMOVAL/INSTALLATION (WITH PANORAMA SUNROOF) .) (See HEADLINER REMOVAL/INSTALLATION (WITH SUNROOF) .) (See HEADLINER REMOVAL/INSTALLATION (WITHOUT PANORAMA SUNROOF) .)
  3. Remove using the procedure shown in the figure below.
    • the figure below shows the left side (same as right side).
    G16695695Courtesy of MAZDA MOTORS CORP.
    PART NAME DESCRIPTION

    Step Part name
    1 Quarter window glass
    (See Quarter window glass removal note ).
    (See Quarter window glass installation note ).
  4. Install in the reverse order of removal.
  5. Perform the power Liftgate (PLG) initialization procedure. (See POWER LIFTGATE (PLG) INITIALIZATION PROCEDURE .)
  6. Initialize power outer mirror retract/return function. (See POWER OUTER MIRROR INITIALIZATION PROCEDURE ).
