Section 47 (On-Board Diagnostic - Standard Deployment Control System)
>>
Foreword [Standard Deployment Control System]
>>
Troubleshooting Procedure
Troubleshooting Procedure
WARNING:
This page is about a different car, the 2016 Mazda CX-5. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Standard Deployment Control System Troubleshooting Chart
Courtesy of MAZDA MOTORS CORP.
