Power Liftgate (PLG) Buzzer Not Activated: Notes
POWER LIFTGATE (PLG) BUZZER NOT ACTIVATED [POWER LIFTGATE (PLG) SYSTEM] DESCRIPTION AND POSSIBLE CAUSES
| Description |
- The power liftgate (PLG) buzzer is not activated during power liftgate (PLG) operation.
|
| Possible Causes |
- Connector or terminal malfunction of the following parts:
- Power liftgate (PLG) control module
- Power liftgate (PLG) buzzer
- Short to ground or open circuit in power liftgate (PLG) buzzer signal circuit
- Short circuit in power liftgate (PLG) buzzer signal circuit
- Power liftgate (PLG) buzzer malfunction
- Power liftgate (PLG) control module malfunction
|
