Power Window Switch Illumination Inspection

Disconnect the negative battery terminal.
Remove the power window main switch. (See POWER WINDOW MAIN SWITCH REMOVAL/INSTALLATION .)

Apply battery positive voltage and connect the ground to the rear map light terminals as indicated in the table

Courtesy of MAZDA MOTORS CORP.

GROUND TERMINAL REFERENCE

B+ Terminal	Ground Terminal	Operation
K	P	LED Turn On

Verify that the LED is turned on.
- If the LED does not turn on, replace the power window main switch. (See POWER WINDOW MAIN SWITCH REMOVAL/INSTALLATION .)
