Trunk Lid Latch And Release Actuator Removal/Installation

WARNING: This page is about a different car, the 2014 Mazda 6. However, it is still accessible from the selected car via links, so may be relevant.
  1. Disconnect the negative battery cable. (See NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION .)
  2. Remove the trunk lid trim. (See TRUNK LID TRIM REMOVAL/INSTALLATION .)
  3. Disconnect the connector.
  4. Remove the bolts.
  5. Remove the trunk lid latch and release actuator from the trunk lid.
  6. Install in the reverse order of removal.
    Fig 1: Rear Door Latch And Lock Actuator With Torque Specifications
    G09787778Courtesy of MAZDA MOTORS CORP.
