Section 1 (On-Board Diagnostics - AWD System)
>>
Foreword [Electronic AWD Control System]
>>
Troubleshooting Procedure
Troubleshooting Procedure
WARNING:
This page is about a different variant/trim than selected.
Fig 1: Electronic AWD Control System Troubleshooting Procedure Flowchart
Courtesy of MAZDA MOTORS CORP.
