MZR 2.5
DTC DETECTION CONDITION AND POSSIBLE CAUSES
| DETECTION CONDITION |
- CAN and inhibitor switch signals do not correspond, while ignition is ON (engine off).
- Starter monitor input circuit voltage less than 4.3 V
under the following conditions:
- IG1 relay output circuit is active
- Shift lever is D range
- Engine is not running
|
| POSSIBLE CAUSE |
- Connector or terminal malfunction
- Transaxle range switch malfunction
- Open circuit in related wiring harness
- Keyless control module malfunction
|
|
|
