Home >> Mazda >> 2007 >> B3000 Base, Standard >> Repair and Diagnosis >> Engine Mechanical >> Auxiliary Emission Control Systems >> Emission System >> Evaporative Emissions (EVAP) System Components >> Notes

Evaporative Emissions (EVAP) System Components: Notes

Fig 1: Evaporative Emissions (EVAP) System Replacement Components With Torque Specifications

G04930132

Courtesy of MAZDA MOTORS CORP.
