General Information [Manual Transaxle G35M-R): Symbols

• There are eight symbols indicating oil, grease, fluids, sealant, and the use of SST  or equivalent. These symbols show application points or use of these materials during service.

SYMBOLS DESCRIPTION

Symbol	Meaning	Kind
Courtesy of MAZDA MOTORS CORP.	Apply oil	New appropriate engine oil or gear oil
Courtesy of MAZDA MOTORS CORP.	Apply brake fluid	New appropriate brake fluid
Courtesy of MAZDA MOTORS CORP.	Apply grease	Appropriate grease
Courtesy of MAZDA MOTORS CORP.	Apply sealant	Appropriate sealant
Courtesy of MAZDA MOTORS CORP.	Apply petroleum jelly	Appropriate petroleum jelly
Courtesy of MAZDA MOTORS CORP.	Replace part	O-ring, gasket, etc.
Courtesy of MAZDA MOTORS CORP.	Use SST or equivalent	Appropriate tools
