Door Lower Latch Rear Removal/Installation

  1. Remove the rear door trim panel. See DOOR TRIM PANEL REAR REMOVAL/INSTALLATION .
  2. Remove the screws (1).
  3. Disconnect the electrical connector.
  4. Position the lower latch (2).
  5. Disconnect cable and remove lower latch.
    Fig 1: Disconnecting Tailgate Lock Rod From Tailgate Lock Remote Control
    G01926008Courtesy of MAZDA MOTORS CORP.
  6. Install in reverse order of removal.
