3.5L (View 3 of 3)

Fig 1: Exploded View Of Exhaust System With Torque Specification (3.5L FWD) (3 Of 3)
G07786933Courtesy of FORD MOTOR CO.
Item Part Number Description
28 W500210 Power steering gear shield bolt (2 required)
29 - Power steering gear shield
30 W706674 Roll restrictor bolt
  1. For additional information, refer to the appropriate procedures in this information.
